TOKO AWS A5.10 ER5356 (AIMg5) Welding Wire
TOKO AWS A5.10 ER5356 (AIMg5), ER4043 Aluminum Alloy Welding Wire. It is Common use in marine, automotive, bicycle frames, and structural components due to excellent corrosion resistance and moderate strength.
Key Advantages
- AWS A5.10 Certified: Compliant with international standards for aluminum welding.
- Excellent Corrosion Resistance: Ideal for marine and salty environments.
- Good Weldability: Minimal post-weld cleanup required.
- Versatile Applications: Suitable for both MIG and TIG processes.
- Moderate Strength: Balanced mechanical properties for various applications.
Performance Benefits
- Consistent Feedability: Optimized for stable arc performance.
- Smooth Welds: Minimal spatter and resistance to hot cracking.
- Moisture-Resistant Packaging: Prevents oxidation during storage.
- Wide Compatibility: Works with 5xxx series aluminum alloys.
Common Applications
- Marine applications and boat building
- Automotive components and frames
- Bicycle frames and components
- Structural aluminum components
- General aluminum fabrication and repair
Technical Specifications
Standard & Classification
| Property | Value |
|---|---|
| Standard | AWS A5.10 |
| Classification | ER5356 (AIMg5) |
| Designation | "ER" indicates suitability as Electrode or Rod |
Chemical Composition
| Element | Percentage |
|---|---|
| Magnesium (Mg) | 4.5–5.5% |
| Manganese (Mn) | 0.05–0.20% |
| Chromium (Cr) | 0.05–0.20% |
| Aluminum (Al) | Balance |
Mechanical Properties (As-Welded)
| Property | Value |
|---|---|
| Tensile Strength | ~38 ksi (262 MPa) |
| Yield Strength | ~17 ksi (117 MPa) |
| Elongation | ~20% |
| Melting Point | ~600°C |
Available Sizes
| Diameter | Form |
|---|---|
| 0.8mm, 1.0mm, 1.2mm, 1.6mm, 2.0mm | Spools for MIG or cut rods for TIG |
Shielding Gas & Welding Parameters
- MIG (GMAW): Argon or argon-helium mixtures
- TIG (GTAW): Argon, using AC or DCEN
- Produces smooth welds with minimal spatter and resistance to hot cracking
Storage & Handling
- Store in a dry, cool environment to prevent oxidation
- Use sealed containers for prolonged storage
Why Choose TOKO ER5356?
- Proven Reliability: Trusted in marine and structural applications.
- Consistent Quality: Uniform feedability and arc performance.
- Global Compliance: Meets international standards for aluminum welding.
